Chrome Steel Precision Spindle Bearings - HS, HSS types

Model NO.: HSS71922E
Price:: £ 2.00-20.00 / piece
Delivery: EXW,FOB,CIF,EXPRESS
Minimum order quantity: 1 piece
Supply Ability: 500000 piece / Month
Country of Origin: China
Stock Time: 15-25 Days

Quantity:

Product Description

MBY® offers comprehensive ranges of angular contact ball bearings, which are available in:
– Single row and double row
– Open and sealed types
– Contact angle of 15, 30 or 40 degree
– Chrome steel, ceramic or hybrid materials
– Polyamide, steel and brass cage assemblies

Note：Swipe left or right to view the complete table!

Bearing Code	Dimensions					Mass	Load rating		Speed		Minor Dimensions
	d	D	B	rsmin	a	(kg)	Cr	Cor	Grease	Oil	da h12	Da H12	ramax
	mm	mm	mm	mm	mm		KN	KN	rpm	rpm	mm	mm	mm
HS7000C.T.P4S.UL	10	26	8	0.3	6	0.02	2.75	1.6	80000	130000	15	20.5	0.3
HS7000E.T.P4S.UL	10	26	8	0.3	8	0.02	2.6	1.5	67000	100000	15	20.5	0.3
HS7001C.T.P4S.UL	12	28	8	0.3	7	0.02	2.7	1.63	70000	110000	17	22.5	0.3
HS7001E.T.P4S.UL	12	28	8	0.3	9	0.02	2.55	1.53	60000	90000	17	22.5	0.3
HS7002C.T.P4S.UL	15	32	7	0.3	8	0.03	3.75	2.45	60000	90000	20	26.5	0.3
HS7002E.T.P4S.UL	15	32	7	0.3	10	0.03	3.55	2.32	50000	75000	20	26.5	0.3
HS7003C.T.P4S.UL	17	35	10	0.3	9	0.04	3.8	2.65	53000	80000	22.5	29	0.3
HS7003E.T.P4S.UL	17	35	10	0.3	11	0.04	3.65	2.5	45000	67000	22.5	29	0.3
HS7004C.T.P4S.UL	20	42	12	0.6	10	0.07	6.2	4.55	45000	67000	27	34.5	0.6
HS7004E.T.P4S.UL	20	42	12	0.6	13	0.07	5.85	4.3	38000	56000	27	34.5	0.6
HS7005C.T.P4S.UL	25	47	12	0.6	11	0.08	6.3	4.9	38000	56000	32	34.5	0.6
HS7005E.T.P4S.UL	25	47	12	0.6	14	0.08	6	4.65	34000	50000	32	34.5	0.6
HS7006C.T.P4S.UL	30	55	13	1	12	0.12	8.8	7.1	32000	48000	37.5	47	1
HS7006E.T.P4S.UL	30	55	13	1	16	0.12	8.3	6.7	28000	43000	37.5	47	1
HS7007C.T.P4S.UL	35	62	14	1	14	0.16	9.3	8.3	28000	43000	43.5	53	1
HS7007E.T.P4S.UL	35	62	14	1	18	0.16	8.8	7.8	24000	38000	43.5	53	1
HS7008C.T.P4S.UL	40	68	15	1	15	0.21	10	9.3	26000	40000	49	58.5	1
HS7008E.T.P4S.UL	40	68	15	1	20	0.21	9.3	8.65	22000	36000	49	58.5	1
HS7009C.T.P4S.UL	45	75	16	1	16	0.27	12.9	12.2	24000	38000	54	65.5	1
HS7009E.T.P4S.UL	45	75	16	1	22	0.27	12.9	11.4	20000	34000	54	65.5	1
HS7010C.T.P4S.UL	50	80	16	1	17	0.3	13.4	13.2	22000	36000	59	70.5	1
HS7010E.T.P4S.UL	50	80	16	1	23	0.29	12.5	12.2	18000	30000	59	70.5	1
HS7011C.T.P4S.UL	55	90	18	1.1	19	0.41	18.6	19	19000	32000	65.5	79	1
HS7011E.T.P4S.UL	55	90	18	1.1	26	0.41	17.6	17.6	17000	28000	65.5	79	1
HS7012C.T.P4S.UL	60	95	18	1.1	19	0.45	19.3	20	18000	30000	70.5	84	1
HS7012E.T.P4S.UL	60	95	18	1.1	27	0.45	18.3	19	15000	24000	70.5	84	1
HS7013C.T.P4S.UL	65	100	18	1.1	20	0.47	20	21.6	17000	28000	75.5	89	1
HS7013E.T.P4S.UL	65	100	18	1.1	28	0.47	19	20	15000	24000	75.5	89	1
HS7014C.T.P4S.UL	70	110	20	1.1	22	0.64	26	28	16000	26000	82	97.5	1
HS7014E.T.P4S.UL	70	110	20	1.1	31	0.64	24.5	26	13000	20000	82	97.5	1
HS7015C.T.P4S.UL	75	115	20	1.1	23	0.68	26.5	29	15000	24000	87	102.5	1
HS7015E.T.P4S.UL	75	115	20	1.1	32	0.68	25	27	13000	20000	87	102.5	1
HS7016C.T.P4S.UL	80	125	22	1.1	25	0.93	31.5	34.5	14000	22000	93.5	111	1
HS7016E.T.P4S.UL	80	125	22	1.1	35	0.93	30	32.5	12000	19000	93.5	111	1
HS7017C.T.P4S.UL	85	130	22	1.1	25	0.97	32	36	13000	20000	98.5	116	1
HS7017E.T.P4S.UL	85	130	22	1.1	36	0.97	30	33.5	11000	18000	98.5	116	1
HS7018C.T.P4S.UL	90	140	24	1.5	27	1.28	37.5	43	12000	19000	105	124.5	1.5
HS7018E.T.P4S.UL	90	140	24	1.5	39	1.27	35.5	40	10000	17000	105	124.5	1.5
HS7019C.T.P4S.UL	95	145	24	1.5	28	1.33	38	44	11000	18000	104	135.5	1.5
HS7019E.T.P4S.UL	95	145	24	1.5	40	1.33	35.5	41.5	9500	16000	104	135.5	1.5
HS7020C.T.P4S.UL	100	150	24	1.5	29	1.39	38	45.5	11000	18000	115	134.5	1.5
HS7020E.T.P4S.UL	100	150	24	1.5	41	1.38	36	42.5	9000	15000	115	134.5	1.5
HS7021C.T.P4S.UL	105	160	26	2	31	1.71	49	58.5	10000	17000	121	143.5	2
HS7021E.T.P4S.UL	105	160	26	2	44	1.71	46.5	54	8500	14000	121	143.5	2
HS7022C.T.P4S.UL	110	170	28	2	33	2.17	50	60	9500	16000	128.5	151	2
HS7022E.T.P4S.UL	110	170	28	2	47	2.17	46.5	56	8000	13000	128.5	151	2
HS7024C.T.P4S.UL	120	180	28	2	34	2.33	51	63	8500	14000	138.5	161	2
HS7024E.T.P4S.UL	120	180	28	2	49	2.33	48	58.5	7500	12000	138.5	161	2
HS7026C.T.P4S.UL	130	200	33	2	39	3.52	65.5	83	7500	12000	152	177.5	2
HS7026E.T.P4S.UL	130	200	33	2	55	3.51	62	78	6700	10000	152	177.5	2
HS7028C.T.P4S.UL	140	210	33	2	40	3.74	6.7	8.8	7000	11000	162	187.5	2
HS7028E.T.P4S.UL	140	210	33	2	57	3.74	6.3	8.15	6300	9500	162	187.5	2
HS71900C.T.P4S.UL	10	22	6	0.3	5	0.01	1.9	1.1	90000	150000	13.5	18	0.3
HS71900E.T.P4S.UL	10	22	6	0.3	7	0.01	1.8	1	75000	120000	13.5	18	0.3
HS71901C.T.P4S.UL	12	24	6	0.3	5	0.01	2.04	1.2	80000	130000	15.5	20	0.3
HS71901E.T.P4S.UL	12	24	6	0.3	7	0.01	1.93	1.14	67000	100000	15.5	20	0.3
HS71902C.T.P4S.UL	15	28	7	0.3	6	0.01	2.8	1.76	67000	100000	18.5	24	0.3
HS71902E.T.P4S.UL	15	28	7	0.3	9	0.01	2.65	1.66	56000	85000	18.5	24	0.3
HS71903C.T.P4S.UL	17	30	7	0.3	7	0.02	2.9	1.9	60000	90000	20.5	26	0.3
HS71903E.T.P4S.UL	17	30	7	0.3	9	0.02	2.7	1.8	50000	75000	20.5	26	0.3
HS71904C.T.P4S.UL	20	37	9	0.3	8	0.04	3.9	2.85	50000	75000	25	31.5	0.3
HS71904E.T.P4S.UL	20	37	9	0.3	11	0.04	3.75	2.7	43000	63000	25	31.5	0.3
HS71905C.T.P4S.UL	25	42	9	0.3	9	0.05	4.25	3.35	43000	63000	30	36.5	0.3
HS71905E.T.P4S.UL	25	42	9	0.3	12	0.05	4	3.15	36000	53000	30	36.5	0.3
HS71906C.T.P4S.UL	30	47	9	0.3	10	0.05	6.4	5.2	36000	53000	34.5	42	0.3
HS71906E.T.P4S.UL	30	47	9	0.3	14	0.05	6	4.9	32000	48000	34.5	42	0.3
HS71907C.T.P4S.UL	35	55	10	0.6	11	0.08	6.95	6.2	32000	48000	41	48.5	0.6
HS71907E.T.P4S.UL	35	55	10	0.6	16	0.08	6.55	5.85	26000	40000	41	48.5	0.6
HS71908C.T.P4S.UL	40	62	12	0.6	13	0.12	7.2	6.95	28000	43000	47	54.5	0.6
HS71908E.T.P4S.UL	40	62	12	0.6	18	0.12	6.8	6.4	24000	38000	47	54.5	0.6
HS71909C.T.P4S.UL	45	68	12	0.6	14	0.13	10	9.65	24000	38000	51.5	61	0.6
HS71909E.T.P4S.UL	45	68	12	0.6	19	0.13	9.5	9	22000	36000	51.5	61	0.6
HS71910C.T.P4S.UL	50	72	12	0.6	14	0.13	10.4	10.2	22000	36000	56	65.5	0.6
HS71910E.T.P4S.UL	50	72	12	0.6	20	0.13	9.8	9.65	20000	34000	56	65.5	0.6
HS71911C.T.P4S.UL	55	80	13	1	16	0.2	13.4	13.7	20000	34000	61.5	73	0.6
HS71911E.T.P4S.UL	55	80	13	1	22	0.2	12.7	12.7	18000	30000	61.5	73	0.6
HS71912C.T.P4S.UL	60	85	13	1	16	0.22	14	14.6	19000	32000	66.5	78	0.6
HS71912E.T.P4S.UL	60	85	13	1	23	0.22	13.2	13.4	17000	28000	66.5	78	0.6
HS71913C.T.P4S.UL	65	90	13	1	17	0.23	14.3	15.3	18000	30000	71.5	83	0.6
HS71913E.T.P4S.UL	65	90	13	1	25	0.23	13.4	14.3	15000	24000	71.5	83	0.6
HS71914C.T.P4S.UL	70	100	16	1	19	0.35	18.3	20	16000	26000	78.5	91	0.6
HS71914E.T.P4S.UL	70	100	16	1	28	0.35	17.3	18.6	14000	22000	78.5	91	0.6
HS71915C.T.P4S.UL	75	105	16	1	20	0.38	19	21.2	16000	26000	83.5	96	0.6
HS71915E.T.P4S.UL	75	105	16	1	29	0.38	17.6	20	13000	20000	83.5	96	0.6
HS71916C.T.P4S.UL	80	110	16	1	21	0.39	21.2	24	15000	24000	88	101.5	0.6
HS71916E.T.P4S.UL	80	110	16	1	30	0.39	19.6	22.4	13000	20000	88	101.5	0.6
HS71917C.T.P4S.UL	85	120	18	1.1	23	0.58	22	26	14000	22000	95.5	109	0.6
HS71917E.T.P4S.UL	85	120	18	1.1	23	0.58	20.4	24.5	12000	19000	95.5	109	0.6
HS71918C.T.P4S.UL	90	125	18	1.1	23	0.59	23.6	28.5	13000	20000	100	114.5	0.6
HS71918E.T.P4S.UL	90	125	18	1.1	34	0.59	22.4	26.5	11000	18000	100	114.5	0.6
HS71919C.T.P4S.UL	95	130	18	1.1	24	0.61	24.5	30	12000	19000	105	119.5	0.6
HS71919E.T.P4S.UL	95	130	18	1.1	35	0.61	22.8	28	10000	17000	105	119.5	0.6
HS71920C.T.P4S.UL	100	140	20	1.1	26	0.86	29	36	11000	18000	112	127.5	0.6
HS71920E.T.P4S.UL	100	140	20	1.1	38	0.86	27.5	33.5	9500	16000	112	127.5	0.6
HS71921C.T.P4S.UL	105	145	20	1.1	27	0.9	30	38	11000	18000	117	132.5	0.6
HS71921E.T.P4S.UL	105	145	20	1.1	39	0.9	28	35.5	9000	15000	117	132.5	0.6
HS71922C.T.P4S.UL	110	150	20	1.1	27	0.93	34.5	44	10000	17000	121	138.5	0.6
HS71922E.T.P4S.UL	110	150	20	1.1	40	0.93	32.5	40.5	9000	15000	121	138.5	0.6
HS71924C.T.P4S.UL	120	165	22	1.1	30	1.3	36.5	48	9000	15000	133.5	151	0.6
HS71924E.T.P4S.UL	120	165	22	1.1	44	1.3	34	45	8000	13000	133.5	151	0.6
HS71926C.T.P4S.UL	130	180	24	1.5	33	1.71	41.5	56	8500	14000	145	164.5	0.6
HS71926E.T.P4S.UL	130	180	24	1.5	48	1.71	39	52	7000	11000	145	164.5	0.6
HS71928C.T.P4S.UL	140	190	24	1.5	34	1.82	42.5	58.5	7500	12000	155	174.5	0.6
HS71928E.T.P4S.UL	140	190	24	1.5	50	1.82	40	54	6700	10000	155	174.5	0.6
HSS7000C.T.P4S.UL	10	26	8	0.3	6	0.02	2.75	1.6	80000		15	20.5	0.3
HSS7000E.T.P4S.UL	10	26	8	0.3	8	0.02	2.6	1.5	67000		15	20.5	0.3
HSS7001C.T.P4S.UL	12	28	8	0.3	7	0.02	2.7	1.63	70000		17	22.5	0.3
HSS7001E.T.P4S.UL	12	28	8	0.3	9	0.02	2.55	1.53	60000		17	22.5	0.3
HSS7002C.T.P4S.UL	15	32	7	0.3	8	0.03	3.75	2.45	60000		20	26.5	0.3
HSS7002E.T.P4S.UL	15	32	7	0.3	10	0.03	3.55	2.32	50000		20	26.5	0.3
HSS7003C.T.P4S.UL	17	35	10	0.3	9	0.04	3.8	2.65	53000		22.5	29	0.3
HSS7003E.T.P4S.UL	17	35	10	0.3	11	0.04	3.65	2.5	45000		22.5	29	0.3
HSS7004C.T.P4S.UL	20	42	12	0.6	10	0.07	6.2	4.55	45000		27	34.5	0.6
HSS7004E.T.P4S.UL	20	42	12	0.6	13	0.07	5.85	4.3	38000		27	34.5	0.6
HSS7005C.T.P4S.UL	25	47	12	0.6	11	0.08	6.3	4.9	38000		32	34.5	0.6
HSS7005E.T.P4S.UL	25	47	12	0.6	14	0.08	6	4.65	34000		32	34.5	0.6
HSS7006C.T.P4S.UL	30	55	13	1	12	0.12	8.8	7.1	32000		37.5	47	1
HSS7006E.T.P4S.UL	30	55	13	1	16	0.12	8.3	6.7	28000		37.5	47	1
HSS7007C.T.P4S.UL	35	62	14	1	14	0.16	9.3	8.3	28000		43.5	53	1
HSS7007E.T.P4S.UL	35	62	14	1	18	0.16	8.8	7.8	24000		43.5	53	1
HSS7008C.T.P4S.UL	40	68	15	1	15	0.21	10	9.3	26000		49	58.5	1
HSS7008E.T.P4S.UL	40	68	15	1	20	0.21	9.3	8.65	22000		49	58.5	1
HSS7009C.T.P4S.UL	45	75	16	1	16	0.27	12.9	12.2	24000		54	65.5	1
HSS7009E.T.P4S.UL	45	75	16	1	22	0.27	12.9	11.4	20000		54	65.5	1
HSS7010C.T.P4S.UL	50	80	16	1	17	0.3	13.4	13.2	22000		59	70.5	1
HSS7010E.T.P4S.UL	50	80	16	1	23	0.29	12.5	12.2	18000		59	70.5	1
HSS7011C.T.P4S.UL	55	90	18	1.1	19	0.41	18.6	19	19000		65.5	79	1
HSS7011E.T.P4S.UL	55	90	18	1.1	26	0.41	17.6	17.6	17000		65.5	79	1
HSS7012C.T.P4S.UL	60	95	18	1.1	19	0.45	19.3	20	18000		70.5	84	1
HSS7012E.T.P4S.UL	60	95	18	1.1	27	0.45	18.3	19	15000		70.5	84	1
HSS7013C.T.P4S.UL	65	100	18	1.1	20	0.47	20	21.6	17000		75.5	89	1
HSS7013E.T.P4S.UL	65	100	18	1.1	28	0.47	19	20	15000		75.5	89	1
HSS7014C.T.P4S.UL	70	110	20	1.1	22	0.64	26	28	16000		82	97.5	1
HSS7014E.T.P4S.UL	70	110	20	1.1	31	0.64	24.5	26	13000		82	97.5	1
HSS7015C.T.P4S.UL	75	115	20	1.1	23	0.68	26.5	29	15000		87	102.5	1
HSS7015E.T.P4S.UL	75	115	20	1.1	32	0.68	25	27	13000		87	102.5	1
HSS7016C.T.P4S.UL	80	125	22	1.1	25	0.93	31.5	34.5	14000		93.5	111	1
HSS7016E.T.P4S.UL	80	125	22	1.1	35	0.93	30	32.5	12000		93.5	111	1
HSS7017C.T.P4S.UL	85	130	22	1.1	25	0.97	32	36	13000		98.5	116	1
HSS7017E.T.P4S.UL	85	130	22	1.1	36	0.97	30	33.5	11000		98.5	116	1
HSS7018C.T.P4S.UL	90	140	24	1.5	27	1.28	37.5	43	12000		105	124.5	1.5
HSS7018E.T.P4S.UL	90	140	24	1.5	39	1.27	35.5	40	10000		105	124.5	1.5
HSS7019C.T.P4S.UL	95	145	24	1.5	28	1.33	38	44	11000		104	135.5	1.5
HSS7019E.T.P4S.UL	95	145	24	1.5	40	1.33	35.5	41.5	9500		104	135.5	1.5
HSS7020C.T.P4S.UL	100	150	24	1.5	29	1.39	38	45.5	11000		115	134.5	1.5
HSS7020E.T.P4S.UL	100	150	24	1.5	41	1.38	36	42.5	9000		115	134.5	1.5
HSS7021C.T.P4S.UL	105	160	26	2	31	1.71	49	58.5	10000		121	143.5	2
HSS7021E.T.P4S.UL	105	160	26	2	44	1.71	46.5	54	8500		121	143.5	2
HSS7022C.T.P4S.UL	110	170	28	2	33	2.17	50	60	9500		128.5	151	2
HSS7022E.T.P4S.UL	110	170	28	2	47	2.17	46.5	56	8000		128.5	151	2
HSS7024C.T.P4S.UL	120	180	28	2	34	2.33	51	63	8500		138.5	161	2
HSS7024E.T.P4S.UL	120	180	28	2	49	2.33	48	58.5	7500		138.5	161	2
HSS7026C.T.P4S.UL	130	200	33	2	39	3.52	65.5	83	7500		152	177.5	2
HSS7026E.T.P4S.UL	130	200	33	2	55	3.51	62	78	6700		152	177.5	2
HSS7028C.T.P4S.UL	140	210	33	2	40	3.74	6.7	8.8	7000		162	187.5	2
HSS7028E.T.P4S.UL	140	210	33	2	57	3.74	6.3	8.15	6300		162	187.5	2
HSS71900C.T.P4S.UL	10	22	6	0.3	5	0.01	1.9	1.1	90000		13.5	18	0.3
HSS71900E.T.P4S.UL	10	22	6	0.3	7	0.01	1.8	1	75000		13.5	18	0.3
HSS71901C.T.P4S.UL	12	24	6	0.3	5	0.01	2.04	1.2	80000		15.5	20	0.3
HSS71901E.T.P4S.UL	12	24	6	0.3	7	0.01	1.93	1.14	67000		15.5	20	0.3
HSS71902C.T.P4S.UL	15	28	7	0.3	6	0.01	2.8	1.76	67000		18.5	24	0.3
HSS71902E.T.P4S.UL	15	28	7	0.3	9	0.01	2.65	1.66	56000		18.5	24	0.3
HSS71903C.T.P4S.UL	17	30	7	0.3	7	0.02	2.9	1.9	60000		20.5	26	0.3
HSS71903E.T.P4S.UL	17	30	7	0.3	9	0.02	2.7	1.8	50000		20.5	26	0.3
HSS71904C.T.P4S.UL	20	37	9	0.3	8	0.04	3.9	2.85	50000		25	31.5	0.3
HSS71904E.T.P4S.UL	20	37	9	0.3	11	0.04	3.75	2.7	43000		25	31.5	0.3
HSS71905C.T.P4S.UL	25	42	9	0.3	9	0.05	4.25	3.35	43000		30	36.5	0.3
HSS71905E.T.P4S.UL	25	42	9	0.3	12	0.05	4	3.15	36000		30	36.5	0.3
HSS71906C.T.P4S.UL	30	47	9	0.3	10	0.05	6.4	5.2	36000		34.5	42	0.3
HSS71906E.T.P4S.UL	30	47	9	0.3	14	0.05	6	4.9	32000		34.5	42	0.3
HSS71907C.T.P4S.UL	35	55	10	0.6	11	0.08	6.95	6.2	32000		41	48.5	0.6
HSS71907E.T.P4S.UL	35	55	10	0.6	16	0.08	6.55	5.85	26000		41	48.5	0.6
HSS71908C.T.P4S.UL	40	62	12	0.6	13	0.12	7.2	6.95	28000		47	54.5	0.6
HSS71908E.T.P4S.UL	40	62	12	0.6	18	0.12	6.8	6.4	24000		47	54.5	0.6
HSS71909C.T.P4S.UL	45	68	12	0.6	14	0.13	10	9.65	24000		51.5	61	0.6
HSS71909E.T.P4S.UL	45	68	12	0.6	19	0.13	9.5	9	22000		51.5	61	0.6
HSS71910C.T.P4S.UL	50	72	12	0.6	14	0.13	10.4	10.2	22000		56	65.5	0.6
HSS71910E.T.P4S.UL	50	72	12	0.6	20	0.13	9.8	9.65	20000		56	65.5	0.6
HSS71911C.T.P4S.UL	55	80	13	1	16	0.2	13.4	13.7	20000		61.5	73	0.6
HSS71911E.T.P4S.UL	55	80	13	1	22	0.2	12.7	12.7	18000		61.5	73	0.6
HSS71912C.T.P4S.UL	60	85	13	1	16	0.22	14	14.6	19000		66.5	78	0.6
HSS71912E.T.P4S.UL	60	85	13	1	23	0.22	13.2	13.4	17000		66.5	78	0.6
HSS71913C.T.P4S.UL	65	90	13	1	17	0.23	14.3	15.3	18000		71.5	83	0.6
HSS71913E.T.P4S.UL	65	90	13	1	25	0.23	13.4	14.3	15000		71.5	83	0.6
HSS71914C.T.P4S.UL	70	100	16	1	19	0.35	18.3	20	16000		78.5	91	0.6
HSS71914E.T.P4S.UL	70	100	16	1	28	0.35	17.3	18.6	14000		78.5	91	0.6
HSS71915C.T.P4S.UL	75	105	16	1	20	0.38	19	21.2	16000		83.5	96	0.6
HSS71915E.T.P4S.UL	75	105	16	1	29	0.38	17.6	20	13000		83.5	96	0.6
HSS71916C.T.P4S.UL	80	110	16	1	21	0.39	21.2	24	15000		88	101.5	0.6
HSS71916E.T.P4S.UL	80	110	16	1	30	0.39	19.6	22.4	13000		88	101.5	0.6
HSS71917C.T.P4S.UL	85	120	18	1.1	23	0.58	22	26	14000		95.5	109	0.6
HSS71917E.T.P4S.UL	85	120	18	1.1	23	0.58	20.4	24.5	12000		95.5	109	0.6
HSS71918C.T.P4S.UL	90	125	18	1.1	23	0.59	23.6	28.5	13000		100	114.5	0.6
HSS71918E.T.P4S.UL	90	125	18	1.1	34	0.59	22.4	26.5	11000		100	114.5	0.6
HSS71919C.T.P4S.UL	95	130	18	1.1	24	0.61	24.5	30	12000		105	119.5	0.6
HSS71919E.T.P4S.UL	95	130	18	1.1	35	0.61	22.8	28	10000		105	119.5	0.6
HSS71920C.T.P4S.UL	100	140	20	1.1	26	0.86	29	36	11000		112	127.5	0.6
HSS71920E.T.P4S.UL	100	140	20	1.1	38	0.86	27.5	33.5	9500		112	127.5	0.6
HSS71921C.T.P4S.UL	105	145	20	1.1	27	0.9	30	38	11000		117	132.5	0.6
HSS71921E.T.P4S.UL	105	145	20	1.1	39	0.9	28	35.5	9000		117	132.5	0.6
HSS71922C.T.P4S.UL	110	150	20	1.1	27	0.93	34.5	44	10000		121	138.5	0.6
HSS71922E.T.P4S.UL	110	150	20	1.1	40	0.93	32.5	40.5	9000		121	138.5	0.6
HSS71924C.T.P4S.UL	120	165	22	1.1	30	1.3	36.5	48	9000		133.5	151	0.6
HSS71924E.T.P4S.UL	120	165	22	1.1	44	1.3	34	45	8000		133.5	151	0.6
HSS71926C.T.P4S.UL	130	180	24	1.5	33	1.71	41.5	56	8500		145	164.5	0.6
HSS71926E.T.P4S.UL	130	180	24	1.5	48	1.71	39	52	7000		145	164.5	0.6
HSS71928C.T.P4S.UL	140	190	24	1.5	34	1.82	42.5	58.5	7500		155	174.5	0.6
HSS71928E.T.P4S.UL	140	190	24	1.5	50	1.82	40	54	6700		155	174.5	0.6
