Features of miniature deep groove ball bearing:
-Metric miniature deep groove ball bearing, like 608ZZ, 627, 628, MR85ZZ, MR106
-inch miniature bearings , like R6, R3, R4ZZ, R6ZZ, R8ZZ, R144, R188
-Flanged inch miniature bearings, like F608ZZ, FR4ZZ, FR6ZZ, FR8ZZ
Application of inch miniature bearings R6:
-inch miniature bearings are deep groove ball bearing with very small sizes.
-inch miniature bearings are widely used in home appliances, ventilators, etc.
| Product Name | r6z r6zz inch size deep groove ball bearing |
| Inner Diameter (ID) | 0.375 inch ( 9.525 mm ) |
| Outer Diameter (OD) | 0.875 inch ( 22.225 mm ) |
| Width/Thickness | Open: 0.2187 inch ( 5.556 mm ); Sealed: 0.2813 inch ( 7.144 mm ) |
| Material | Chrome Steel Rings + Chrome Steel Balls + Steel Cage + Metal Shields |
| Row Number | Single Row |
| Radial Clearance | C0 ( 2um-13um ) |
| Lubrication | Grease |
| Precision | P0 (ABEC-1), P6 (ABEC-3), P5 (ABEC-5), P4 (ABEC-7) |
| Load Ratings | Dynamic: 3.35 kN; Static: 1.41 kN |
| Weight/Per Unit | 0.0117 kg |
| MOQ | Minimum Order Quantity: 10pcs for Neutral; 1000pcs for Custom Made |
| Main Application | Machinery, Electric Motors |
| Leading Time | Neutral: In 3 days; Custom Made: In 20 working days |
Packing Details:
1. Plastic Tubes or Small Boxes ( Usually 10pcs in one plastic tube for steel bearings, 1pcs in one small box for ceramic bearings );
2. Cartons ( No more than 30kg for one carton );
3. Pallet ( Usually more than 400kg totally will use pallet )
Delivery/Shipping:
1. FedEx, UPS, DHL, TNT ( The most fastest shipping methods for small packages, usually it takes 3-6 days for shipping );
2. China Post EMS ( Slow, usually it takes 15 working days for shipping );
3. By Air ( Usually more than 150-200kg and it takes about 5-7 woking days for shipping, fast but expensive);
4. By Sea ( Usually more than 100kg and it usually takes 25-30 working days for shipping, slow but cheap ).
Q: What kinds of bearing you supply?
A: main products are ball bearing, plastic bearing, ceramic bearing, needle bearings and
industrial tools, etc, as per customers' drawings or samples.
Q: When inspecting bearings, what should we need to consider?
A: The precision of the bearings (dimension tolerance, loading rate), internal
clearance and hardness under heat treatment, structure of cage and material.
Q:Your product certifications?
A: ISO 9001:2008, RoHS.
Q: Can I have a sample order?
A: Yes, it is available to check quality first. Mixed samples are also acceptable.
Q: What about the lead time?
A: 3-7 days for samples, 3-4 weeks for mass production.
Q:Whatis your payment method?
A: We accept T/T, PAYPAL or Western Union, credit card or via ALIBABA Assurance order.
